Automatic Web-Fed Hot Foil Stamping Machine

Automatic Web-Fed Hot Foil Stamping Machine is designed as the new generation product; it is used for automatic stamping roll material that after the printing, laminating. It is suitable for the production of paper box, paper cup, Surround-Bidding label, card paper pressing convex, portable paper bag, paper cover,PVC, and various plastic material etc. The main machine and frame adopt the advanced resin sand technical, which ensures machine be more stable. The main components are controlled by the Japan Mitsubishi PLC. The main motor is controlled by AC frequency conversion speed regulator; the main transmission system is equipped by air clutch brake equipment, which makes the machine running steadily. The machine equipment adopts high precision color photo-electrical automatic trace detection, servo motor automatic locating system. Material automatic loading, equipping --- feeder automatic correct equipment. It has advantages of easy length adjustment, high precision locating, stable feeding, even tension, compact structure, high automatic, easy operation, stable property and so on. Technical Parameter: Model TYM1050JT Max. roll paper diameter(mm) 1200mm Max. feeding paperlength(mm) 750mm Max. sheet size(mm) 1050mm×750mm Max. stamping speed 5000times/h Max. working speed 6000times/h Foil feeding shafts 3 groups Zones individually heated 10 zones 3kw Main motor power 15kw Heated plate power 30kw Paper range 150g-1000g/sm Max. working pressure 250T Machine weight 18T Overall machinedimensions(mm) 13000×4000×2200
